This tutorial was originally published in 2005. Since that time, web technologies have changed and the java applet that this program runs in is no longer supported by Chrome, Firefox, and Microsoft Edge web browsers. However, you can use Microsoft Internet Explorer 11. The Bridge Designer is perhaps the greatest online tool for building model bridges.
It allows you to design a virtual truss, put a load on in, and it calculates how the forces are spread out. You can use this as a design tool as well as an evaluative tool. Once you have built and tested a bridge, plug in your design and load when failure occurred and it will show you how much force was on each member. I was first introduced to the Bridge Designer by a civil engineer, who explained to me the usefulness of the free program. However, it took me, a 6th grader at the time, over a year of playing around with it to finally figure it out. This program has some limitations that you must understand if you are going to use it properly. Watch the video tutorial or read through the steps.
The Bridge Designer allows you to create a virtual truss, put a load on it, and see how the load is spread out. It is very useful to use after you test a bridge to failure, then plug in the bridge design, and see how much force it took to break it. Here is a text version of the video.
When you first load the program, you are presented with this: To begin, you will need to click the “Add Nodes” button. A “node” is simply a joint. You must add the joints before adding the actual members.
This course covers design of new bridges and evaluation of existing bridges in accordance with current AASHTO specifications. The procedures and requirements of. Bridge Designer. Engineering Innovation, Center for Educational Outreach. Summer Programs at Johns Hopkins.
Usually, I start with the bottom left corner of the bridge, and then count over to the right however many squares as my bridge is long. I count one square per inch. If your bridge is really short, you might do two squares per inch. Or if it is really long, 1/2 square per inch. After I have the bottom length, I add the top nodes. Pc Pettersson Und Findus Skype.
It might look something like this: Now it is time to add the members. Click the “Add Members” button. Left click on one of the nodes you have added, and drag the mouse over to the next one. You must hold down the left button to do this. It doesn’t matter what order you add the members, but you must connect every node. After adding all the members, click the “Calculate” button on the bottom. Now look just below the top buttons.
In red, you should see something like “There must be one fixed and one roller node”. If you see “Members +3 must equal twice the Nodes”, you need to adjust either the number of nodes or members. Once everything is okay, click the “Fixed node” button which is one the bottom left. Then click the bottom left node. Cyber Cafe Referral Program Ro2 on this page.
That node should turn yellow. Make the bottom right node the “Horizontal rolling node”, it should turn red. Alright, you’re almost done. Update Statistics Sql Server 2008 All Tables Math. Click the “Add a Load” button, and choose which node to put it on. You can add more than one load if you want.
